4074
- PRODUCT DETAIL
40000rpm 400kv 3000w 1Nm dc motor for robot RT4074-400KV
RT Motor
4074-400KV
Motor type
Inner rotor
Construction
18N/6P
Winding Turns
7T-Y
Working Voltage
20-36V
Max RPM
40000
RPM/V
400
No Load Current
1.5A
@10V
Rated Torque
0.35N*M
Rated Current (A)
13.5
Max Efficiency
>90%
Dimension(mm)
D40*L74
Shaft Dimension
D5*16mm
M3*25
Sensored or Sensorless
Sensorless
Max Power(10S)
3KW
Max Torque(N*M)
1.0N*M
Max Current (A)
50
Net Weight (kg)
0.37
Cooling device
Water
Protection
IP47
