Category: Middle drive motor
Motor Type: PMSM Motor
Pole Pairs: 5
MAX Efficiency>=94%
Max Torque: >170Nm after gear reduction
Rated Power: 10000W
Max Power: 15000W
Rated Voltage: 72V( 48-96V Can be optional)
Sensor Type: encoder
Rated Speed RPM: 5500RPM
